简单的RGB转HSV代码

c
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
// Copyright (c) 2014, Jan Winkler <winkler@cs.uni-bremen.de>
// All rights reserved.
//
// Redistribution and use in source and binary forms, with or without
// modification, are permitted provided that the following conditions are met:
//
//     * Redistributions of source code must retain the above copyright
//       notice, this list of conditions and the following disclaimer.
//     * Redistributions in binary form must reproduce the above copyright
//       notice, this list of conditions and the following disclaimer in the
//       documentation and/or other materials provided with the distribution.
//     * Neither the name of Universität Bremen nor the names of its
//       contributors may be used to endorse or promote products derived from
//       this software without specific prior written permission.
//
// THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
// AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
// IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
// ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE
// LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
// CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF
// SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
// INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
// CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
// ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
// POSSIBILITY OF SUCH DAMAGE.

/* Author: Jan Winkler */


#include <iostream>
#include <cstdlib>
#include <cmath>

using namespace std;


/*! \brief Convert RGB to HSV color space

  Converts a given set of RGB values `r', `g', `b' into HSV
  coordinates. The input RGB values are in the range [0, 1], and the
  output HSV values are in the ranges h = [0, 360], and s, v = [0,
  1], respectively.

  \param fR Red component, used as input, range: [0, 1]
  \param fG Green component, used as input, range: [0, 1]
  \param fB Blue component, used as input, range: [0, 1]
  \param fH Hue component, used as output, range: [0, 360]
  \param fS Hue component, used as output, range: [0, 1]
  \param fV Hue component, used as output, range: [0, 1]

*/
void RGBtoHSV(float& fR, float& fG, float fB, float& fH, float& fS, float& fV) {
  float fCMax = max(max(fR, fG), fB);
  float fCMin = min(min(fR, fG), fB);
  float fDelta = fCMax - fCMin;

  if(fDelta > 0) {
    if(fCMax == fR) {
      fH = 60 * (fmod(((fG - fB) / fDelta), 6));
    } else if(fCMax == fG) {
      fH = 60 * (((fB - fR) / fDelta) + 2);
    } else if(fCMax == fB) {
      fH = 60 * (((fR - fG) / fDelta) + 4);
    }

    if(fCMax > 0) {
      fS = fDelta / fCMax;
    } else {
      fS = 0;
    }

    fV = fCMax;
  } else {
    fH = 0;
    fS = 0;
    fV = fCMax;
  }

  if(fH < 0) {
    fH = 360 + fH;
  }
}


/*! \brief Convert HSV to RGB color space

  Converts a given set of HSV values `h', `s', `v' into RGB
  coordinates. The output RGB values are in the range [0, 1], and
  the input HSV values are in the ranges h = [0, 360], and s, v =
  [0, 1], respectively.

  \param fR Red component, used as output, range: [0, 1]
  \param fG Green component, used as output, range: [0, 1]
  \param fB Blue component, used as output, range: [0, 1]
  \param fH Hue component, used as input, range: [0, 360]
  \param fS Hue component, used as input, range: [0, 1]
  \param fV Hue component, used as input, range: [0, 1]

*/
void HSVtoRGB(float& fR, float& fG, float& fB, float& fH, float& fS, float& fV) {
  float fC = fV * fS; // Chroma
  float fHPrime = fmod(fH / 60.0, 6);
  float fX = fC * (1 - fabs(fmod(fHPrime, 2) - 1));
  float fM = fV - fC;

  if(0 <= fHPrime && fHPrime < 1) {
    fR = fC;
    fG = fX;
    fB = 0;
  } else if(1 <= fHPrime && fHPrime < 2) {
    fR = fX;
    fG = fC;
    fB = 0;
  } else if(2 <= fHPrime && fHPrime < 3) {
    fR = 0;
    fG = fC;
    fB = fX;
  } else if(3 <= fHPrime && fHPrime < 4) {
    fR = 0;
    fG = fX;
    fB = fC;
  } else if(4 <= fHPrime && fHPrime < 5) {
    fR = fX;
    fG = 0;
    fB = fC;
  } else if(5 <= fHPrime && fHPrime < 6) {
    fR = fC;
    fG = 0;
    fB = fX;
  } else {
    fR = 0;
    fG = 0;
    fB = 0;
  }

  fR += fM;
  fG += fM;
  fB += fM;
}


int main(int argc, char** argv) {
  float fR = 0, fG = 0, fB = 0, fH = 0, fS = 0, fV = 0;

  fH = 146.0;
  fS = 0.19;
  fV = 0.66;

  HSVtoRGB(fR, fG, fB, fH, fS, fV);

  /*fR = 136.0;
    fG = 168.0;
    fB = 150.0;

    RGBtoHSV(fR, fG, fB, fH, fS, fV);*/

  cout << "[RGB] "
       << "Float:   (" << fR << ", " << fG << ", " << fB << ")" << endl
       << "      Integer: (" << (255 * fR) << ", " << (255 * fG) << ", " << (255 * fB) << ")" << endl;
  cout << "[HSV] (" << fH << ", " << fS << ", " << fV << ")" << endl;

  return EXIT_SUCCESS;
}
